FOOD GRADE EPOXY COATING
Raycote EP lntercoat 144 is solvent free, two pack, epoxy coatings specially formulated for the coating applications in contact with potable water. Epoxy coating system consist of two components which, when blended and applied as a film, react chemically to form a protective film of high integrity, excellent adhesion, corrosion resistant, tough and high impact resistance. The product is designed to be spray applied using plural feed airless spray equipment or by brush. It complies with BS 6920, AWWA C210 and NSF/ ANSI 61 standards.
Types of casing insulator:
Contact
- Halol, Navaria, Gujarat 389350, India
-
+91 84088 87790
+91 9769065836 - snisales@impac-group.in
Brochures
Download the SNI India Brochure to explore our exceptional corrosion protection solutions for the oil and gas industry.
- Suitable for potable water applications.
- No VOC and no isocyanates
- High performance epoxy coating used to protect concrete and steel
- Excellent Wetting properties to bare steel- Exceptional adhesion, cathodic dis-bondment and soil stress
- resistance on bare steel.
- Easy to mix – save time
- Excellent resistance to abrasion and mechanical damage.
- Same formula can be hand or spray applied- Flexibility in difficult to coat field conditions
- Adjustable flow rates
- NSF International Standard NSF
- Water regulations advisory scheme (WRAS), UK or
- Central Food Research Institute, Mysore
- BS 6920 UK.
- Mixing Ratio : 3:1
- Color : Red /Gray
- Film Thickness per coat : 400 ~500 Micron
- Volume solids : 100%
- Drum : Part A : 200 L
- Part B : 200 L : Drum size can be supplied against Customer specific requirement
- Kits: (1.3 Gal/ 5 L), (0.67 Gal / 2.5 L), (0.27 Gal/ 1 L), (0.13 Gal / 0.5 L).
Before application all steel surfaces should be clean, dry and free from dust. Abrasive blast cleaned to NEAR WHITE as per ISO standard SA2 ½, SSPC-10, SSPC-SP5, NACE 2 and equivalent to give a nominal 50-80 micron profile. Coating is applied by plural feed airless two component spray machine to the required thickness on the substrate.
